Siemens NX provides a comprehensive powerful tool for the entire process of mold making and fabrication including: Molder variation (Draft, thickness distribution), mold structure design, Mold machining (CAM), automatic electrode design, and from Version NX8.5 allows integration of plastic injection simulation with Easy fill modules, with synchronous integration capability. Thus Siemens NX allows users to implement the entire process of designing and manufacturing molds on a single software platform interface thereby shortening time and cost.

There are many industrial designs and many different types of molds to make the product. One of the molds used to make the product is the forging die with the advantages of ensuring good mechanical properties. Characteristics of products that require high mechanical strength. However, to produce forging die also requires a lot of design experience to optimize the stamping process, maximizing the material embossing, reducing the number of attempts and correcting the mold. The following software solutions meet the above requirements to reduce costs and time to market products.

Stamping presses are used to manufacture products in many industrial fields, especially in the field of automotive, motorbike, products are often large size, high complexity, almost of mold maker need to test on several time after design and manufacture. The CAD / CAM / CAE solution is not as feasible in the design and manufacture of this mold. Below is the best solution for the design and manufacture of stamping molds including from the initial design stage to the mold design, Products and molding with CNC machining centers

Total and integrate solutions for injection molding from part design, analysis to complete manufacturing included Automatic create parting surface, filling, packing, cooling analysis and optimize mold system. Reduce design cost, manufacturing cost.

The solutions software guides you through all of the stages required to design a progressive die, automating the most tedious tasks and streamlining the most complex processes. NX Progressive Die Design is a comprehensive solution for both straight break and freeform sheet metal parts. You can design the complete die structure with associativity to the part design at every stage
